INPUTS / OUTPUTS : 8 Un-Balanced (Input / Output)
FREQUENCY RESPONSE : 25Hz to 20,000Hz
ECHO/REVERB SYSTEM: Digital Echo 20-400 Mil. Sec.
INPUTS: Mic Input 2KΩ Mono Line Input 10kΩ
FADERS: 30mm Silde for each Channel
INPUT GAIN: -10dB to – 50dB
S/N RATIO: 70dB
DISTORTION:0.01%
TONE CONTROLS: Bass ± 16dB , Mid ± 10dB, Treble ± 16 dB
EFFECT RETURN: -30dB Max
EFFECT SEND( Pre fader): 0dB to 505V Max
CH. SIGNAL INDICATORS: Clip LED, output Metering 10 Segment LED
POWER SUPPLY: Ac: 220 -240V/ 50-60Hz
