RealAudio DJ-5000 Class AB Dual Channel Power Amplifier
RealAudio – DJ-5000 A High-Performance Class AB Dual-Channel Power Amplifier Built for Professional Audio Applications Where Power, Reliability, and Sound Quality Are Essential. Designed for Djs, Live Concerts, Event Productions, Auditoriums, Rental Companies, and Professional P.a. Systems, the Dj-5000 Delivers Deep Bass, Crystal-clear Audio, and Outstanding Dynamic Performance.
Technical Specifications
Output Power
- 8Ω Stereo/Mono: 2 × 1300W
- 4Ω Stereo/Mono: 2 × 1800W
- 2Ω Stereo/Mono: 2 × 2500W
Performance
- Output Circuitry: Class AB
- Frequency Response: 20Hz – 20kHz ±1dB
- Input Sensitivity: 0.707V (0dBm)
- Input Impedance (Balanced/Unbalanced): 20kΩ / 10kΩ
- THD+N: ≤ 1%
- Signal-to-Noise Ratio: >102dB
- Damping Factor: >1000
System Features
- Dual Channel Crossover
- Front-to-Back Cooling System
- 4 Variable-Speed Cooling Fans
Protection Features
- Soft Start-Up Protection
- Short Circuit Protection
- Under-Impedance Protection
- Over-Current Protection
- Clip Limiter Protection
- Thermal Protection
Physical Specifications
- Rack Space: 3U
Applications
- Professional DJ Sound Systems
- Live Concerts & Events
- Rental Sound Companies
- Auditoriums & Banquet Halls
- Houses of Worship
- Clubs & Entertainment Venues
- Outdoor Sound Reinforcement
- Professional P.A. Systems
