RealAudio Audio Mixer with Echo & MP3 Player | Professional Mixer Amplifier
The RealAudio 12-Channel Audio Mixer is designed to deliver professional sound performance for DJ setups, live events, conferences, religious gatherings, and studio applications. Featuring 12 unbalanced input/output channels, adjustable digital echo effects, and precise tone controls, it ensures superior audio clarity and flexibility. The built-in MP3 player and advanced mixing functions allow seamless audio management, while individual 30mm channel faders provide smooth control. With a wide frequency response of 25Hz–20kHz, ultra-low 0.01% distortion, and LED signal monitoring, this mixer delivers reliable and crystal-clear sound reproduction, making it an ideal choice for professional audio installations and live performances.
SPECIFICATIONS
• Inputs / Outputs: 12 Unbalanced Input & Output Channels
• Frequency Response: 25Hz – 20kHz
• Echo/Reverb System: Digital Echo (20ms – 400ms Delay)
• Microphone Input: 2kΩ
• Mono Line Input: 10kΩ
• Channel Faders: 30mm Smooth Slide Faders
• Input Gain Control: -10dB to -50dB
• Signal-to-Noise Ratio: 70dB
• Total Harmonic Distortion (THD): 0.01%
• Bass Control: ±16dB
• Mid Control: ±10dB
• Treble Control: ±16dB
• Effect Return: -30dB Max
• Effect Send (Pre-Fader): 0dB to 0.5V Max
• Channel Signal Indicators: Clip LED
• Output Metering: 10-Segment LED Display
• Power Supply: AC 220V – 240V, 50/60Hz
APPLICATIONS
• DJ Sound Systems
• Live Stage Performances
• Public Address Systems
• Conference Halls
• Schools & Auditoriums
• Religious Gatherings
• Event Management
• Studio & Sound Reinforcement Applications
