CA-20

Brand:

MODEL-CA-20

Professional Class AB Power Amplifier

Short Description:
MODEL-CA-20 is a high-performance Class AB professional power amplifier designed for powerful and reliable sound reinforcement. With strong output power, dual channel crossover, advanced protection systems, and efficient cooling, it delivers crystal-clear audio performance for DJs, live events, clubs, auditoriums, and professional PA applications.





₹54,575.00

Add to wishlist
0 People watching this product now!

SPECIFICATIONS

MODEL-CA-20

OUTPUT POWER:(8Ω) STEREO/MONO: 2 X 1300W

OUTPUT POWER:(4Ω) STEREO/MONO: 2 X 1800W

OUTPUT POWER:(2Ω) STEREO/MONO: 2 X 2500W

OUTPUT CIRCUITRY: CLASS AB

FREQUENCY RESPONSE: 20HZ–20KHZ ± 1DB

INPUT SENSITIVITY: 0.707V (0DBM)

INPUT IMPEDANCE BALANCED / UNBALANCED: 20KΩ / 10KΩ

THD+N: ≤ 1%

S/N RATIO: >102DB

DAMPING FACTOR: >600

CROSSOVER: DUAL CHANNEL CROSSOVER

COOLING SYSTEM: FRONT-TO-BACK VIA 4 VARIABLE-SPEED FANS

PROTECTION: SOFT STARTUP, SHORT, UNDER-IMPEDANCE, OVER-CURRENT, CLIP LIMITER, THERMAL PROTECTION

RACK SPACE: 3U
